30606 – Power Supply IC for Automotive ECU – Multi-Output Voltage Regulator

The 30606 is a multi-output power supply integrated circuit specifically designed for automotive engine and body control modules.

It provides multiple regulated voltage rails from a single input supply, typically generating 5V, 3.3V, and a tracking or standby output for microcontroller, sensor, and transceiver power needs.

This device operates from an input voltage range of 4.5V to 28V, with transient protection up to 40V, making it compatible with 12V automotive electrical systems under cranking and load-dump conditions.

Each output rail includes independent overcurrent and short-circuit protection, while a global thermal shutdown feature prevents damage during extreme overload events.

The 30606 integrates a power-on reset generator and a precision voltage reference, ensuring reliable startup sequencing for the main microprocessor.

An optional external capacitor adjusts the reset delay time, allowing flexible system integration across different ECU architectures.

Built-in diagnostic outputs report undervoltage and overtemperature conditions to the host controller, enabling proactive fault handling.

Fabricated with automotive-grade process technology, the 30606 is AEC-Q100 qualified and supports an operating junction temperature range of -40°C to 150°C.

For designers of cost-sensitive yet robust ECU power architectures, the 30606 reduces component count compared to discrete regulator solutions, saving PCB space and improving system reliability.
